LKAV3516 Police IP66 MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power

1
MOQ
USD, RMB
Price
LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power
Features Gallery Product Description Request A Quote
Features
Specifications
Encryption: AES
Frequency: 350MHz-4GHz Customizable
RF Bandwidth: 2/5/10/20/40MHz
Power Output: 36dBm (4W MIMO 2x2)
Battery Life: Up To 4 Hours
Voltage: DC 12V
Application: Marine/Tunnel/Underground Communicate
Highlight:

cofdm video transmitter

,

wireless av sender

Basic Infomation
Place of Origin: Shenzhen China
Brand Name: OEM / LinkAV
Certification: CE
Model Number: LKAV3516
Payment & Shipping Terms
Packaging Details: Brown Carton
Delivery Time: 15 working days
Payment Terms: T/T, PayPal, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1000pcs/Month
Product Description

Police IP66 MESH Radio 4G GPS/BD PPT WiFi AES Encryption with LCD Digital Indicator and Battery Power



Introduction

The LKAV3516 is an IP66 rugged MESH Radio integrates 4G, GPS/BD, PTT and 2.4G WiFi. It supports HDMI and LAN input, with LCD digital indicator to display device status in real time, and buckle-up battery for easy replacement. It can be applied to multiple scenarios such as a manpack radio, a fixed point relay, or to be installed on a moving vehicle, a robot, or an unmanned ship, etc.



Features

Supports 4G-LTE network

Supports LAN and HDMI inputs

Supports 2.4G MIMO WiFi and GPS/BD

Supports voice intercom

High bandwidth up to 82Mbps

With LCD to show device parameters in real time

Optional buttons for parameters configuration

Full IP duplex transparent data transmission

Flexible networking and rapid deployment

Rugged three-proof IP66 design

Convenient operation and maintenance



Specification

Transmission Characteristics
Default Frequencies 1400-1460MHz (562-612MHz)
Channel Bandwidth 5M/10M/20MHz/40MHz
RF Channel 2T2R
Output Power 36dBm (2x2W)
WIFI 2.4G WIFI (2x100mw MIMO)
Modulation Type

DSSS/CCK BPSK/QPSK OFDM

BPSK/QPSK/16-QAM/64-QAM

Data Rate Up to 82Mbps
Network Capability 9 hops and no less than 64 nodes
Encryption AES
Electrical Characteristics
Working Voltage DC 12V
Battery Capacity 1137dBmh
Power Consumption <16W Average
Physical Characteristics
Weight 2.5kg (w/ battery)
Dimensions 240*150*60mm
IP Rating IP66
Storage Temp. -45℃~85℃
Working Temp. -40℃~65℃
Working Humidity 5%RH-95%RH (Non-Condensing)



Dimensions

LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 0



Panel Description



Front View

LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 1

① Battery butterfly clasp

② Power input port for main body

③ Configuration buttons for frequency, bandwidth and distance

④ Digital LCD indicator

⑤ HDMI input interface

⑥ Power push button

⑦ LAN interface (RJ45)

⑧ MESH antenna interface-2

⑨ WIFI antenna interface

⑩ MESH signal LED indicator

4G antenna interface

PTT Mic interface

GPS/BD antenna interface

MESH antenna interface-1



Rear View

LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 2

① Battery indicator

② Mounting hole



Inner View

LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 3

① Battery +/- contact pins

② SIM card slot





Topology Diagram

■ Star Type
LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 4

■ Mesh Type
LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 5

■ Random Type

LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 6





Application Scenario



LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 7

LKAV3516 Police IP66  MESH Radio 4G GPS/BD PTT WiFi AES Encryption with LCD Digital Indicator and Battery Power 8
